Low Noisy Small Servo Driven Sanitary Napkin Wrapping Machine
Description:
1. High quality. Our wrapping machine adopts famous imported brand spare parts, including limit sensors, bearings, belts, and HMI touch screen. These spare parts are installed by professional workers for maximum working efficiency. It is a good automatic wrapping machine.
2. Perfect finished package. The sealing edging is neat and overlay. The package with sanitary pads is beautiful, increasing the product's grade and improving customers' satisfaction.
3. Advanced security protection. One is the limited protection of technical parts. The other is the current overload protection. Double protection provides the machine with more service -life.
4. Online bag making function. It adopts the double unwinding storage racks, achieving non-stop refueling. The heat sealing device is provided by the Tokyo Institute of Technology in Japan and Ropex in Germany, keeping the heat system stable.
Specification:
| Model | QB-100G |
| Control system | Full servo motor |
| Package material | Composite film |
| Pack process | making tube in roll bag online |
| Package size | L(80-120)*W(30-90)*H(80-180)mm |
| Machine dimension | L(6000)*W(950)*H(2000)mm |
| Weight | 1000kg |
| Power supply | 3 phase, 380V+N+PE,±5%,50HZ |
| Capacity | 25KW |
| Air consumption | 0.5m³/min |
| Pneumatic | 0.6Mpa |
| Certification | ISO/CE |
| Speed | 55-65 bags/min |
Competitive Advantage:
We can customize the most suitable scheme for you according to your factory layout and product characteristics.
Packaging & Shipping
1. Size: According to sanitary napkin packing machine size.
2. Weight: About 950kg.
3. Packaging Details: The normal package is an aluminum paper covering and uses a strong PE film wrapping around each section, then each section packing in a wooden case. (Machine Size: L*W*H)
4. Shipping: By sea.
